操作参数：
最大液压/水压： 400bar
最大转速： 500r/min
最大温度： 120℃
|
Hose Connection Port |
Ordering Number | |||
|---|---|---|---|---|
| Standard | E.L.S. | Rotor Thread | ||
| 1/4" NPT | D8-004-214 | 1/4" NPT RH | ||
| D8-004-215 | 1/4" NPT LH | |||
| G 1/4" (BSP) | D8-003-210 | G 1/4" (BSP) RH | ||
| D8-003-211 | G 1/4" (BSP) LH | |||
| 3/8" NPT | D10-004-214 | 3/8" NPT RH | ||
| D10-004-215 | 3/8" NPT LH | |||
| G 3/8" (BSP) | D10-003-210 | G 3/8" (BSP) RH | ||
| D10-003-211 | G 3/8" (BSP) LH | |||
| 1/2" NPT | D12-004-214 | 1/2" NPT RH | ||
| D12-004-215 | 1/2" NPT LH | |||
| G 1/2" (BSP) | D12-003-210 | G 1/2" (BSP) RH | ||
| D12-003-211 | G 1/2" (BSP) LH | |||
| 3/4" NPT | D20-004-214 | 3/4" NPT RH | ||
| D20-004-215 | 3/4" NPT LH | |||
| G 3/4" (BSP) | D20-003-210 | G 3/4" (BSP) RH | ||
| D20-003-211 | G 3/4" (BSP) LH | |||
| 1" NPT | D25-004-214 | 1" NPT RH | ||
| D25-004-215 | 1" NPT LH | |||
| G 1" (BSP) | D25-003-210 | G 1" (BSP) RH | ||
| D25-003-211 | G 1" (BSP) LH | |||
| 1 1/4" NPT | D32-004-214 | 1 1/4" NPT RH | ||
| D32-004-215 | 1 1/4" NPT LH | |||
| G 1 1/4" (BSP) | D32-003-210 | G 1 1/4" (BSP) RH | ||
| D32-003-211 | G 1 1/4" (BSP) LH | |||
| 1 1/2" NPT | D40-004-214 | 1 1/2" NPT RH | ||
| D40-004-215 | 1 1/2" NPT LH | |||
| G 1 1/2" (BSP) | D40-003-210 | G 1 1/2" (BSP) RH | ||
| D40-003-211 | G 1 1/2" (BSP) LH | |||
