Deublin HPS系列瓦楞纸用高压蒸汽接头
Duoflow Steam Union for Corrugators - 1-1/2"

特点：
—— 单通道与双通道设计
—— 自带支撑旋转接头
—— 密封与轴承采用特殊碳石墨
—— 凸面结构密封环更适合用于机械和热追振动
—— 采用外部机构通过端盖调整虹吸管
—— 镀镍可锻铸铁壳体
—— 不锈钢弹簧
—— 大型钢转体设计
—— 双轴承可延长使用寿命

技术参数：
Maximum Saturated Steam Pressure： 250 PSI 17 bar
Maximum Speed： 400 RPM 400/min
Maximum Temperature： 400°F 200°C

DEUBLIN
HPS Series for High Pressure Steam
Service in Corrugators
- monoflow and duoflow design
- self-supported rotating union
- seals and bearings made of special Carbon Graphite
- convex seal ring better suited to handle mechanical and
thermal shock
- external mechanism to adjust siphon pipe through end cap
- nickel-plated front and rear end cap
- nickel-plated ductile iron housing
- stainless steel spring
- heavy duty steel rotor design
- dual bearings for extended service life

订货型号：

C15D-004-02-3A
